Tri-Fold LED Poster Screen FEATURES:
* With sideward foldable frame (fold from both sides), the Tri-fold LED digital poster giving a bigger display area in
1280x1920mm. Allow one unit meets customer needs while saving transportation space and costs
* Side Forward folding into dual faces LED display poster
* Side Forward folding allow for Multi angle display, capable of meeting complex and varied application scenarios
* Upgrade control solution, no need complicated operation: Open it to get a large screen, fold it to get a double-sided screen, no need to operate through software. (Compared with the old solution, it needs to resend the screen connection file through software to achieve the effect of double-sided screen and single-sided independent display).
* This LED poster video display allow for multi-pieces link together and get even bigger display screen (P1.53 is 2pcs linkable, P1.86 is 3pcs linkable, P2.5 is 4pcs linkable)
* The LED display panels adopt GOB technology, which provide the LED Poster Surface protection from attack, dust and water.
* Back access to maintenance.
* Floor-standing with wheel for easy moving.
* Out of Box plug and play, No installation required.
Poster led display Specifications:
| Pixel Pitch | P1.25 | P1.53 | P1.86 | P2 | P2.5 |
| LED type | SMD1010(S/G/C) | SMD1212(S/G/C) | SMD1515(S/G/C) | SMD1515(S/G/C) | SMD1515/2020(S/G/C) |
| Physical Density(Dots/㎡) | 640000 | 409600 | 288888 | 250000 | 160000 |
| Screen resolution(dots) | 2*512X1536 | 2*416X1248 | 2*344X1032 | 2*320X960 | 2*256X768 |
| Module size(mm) | 320X160 | 320X160 | 320X160 | 320X160 | 320X160 |
| Display dimension(mm) | 2*640X1920 | 2*640X1920 | 2*640X1920 | 2*640X1920 | 2*640X1920 |
| Overall Dimensions (mm) | 646X2090X110 | 646X2090X110 | 646X2090X110 | 646X2090X110 | 646X2090X110 |
| Maintenance mode | Front | Front | Front | Front | Front |
| Materials | Galvanized sheet | Galvanized sheet | Galvanized sheet | Galvanized sheet | Galvanized sheet |
| Brightness(CD/㎡) | ≥600 | ≥600 | ≥800 | ≥800 | ≥800 |
| Color temperature(K) | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optional | 5000-12000 Optiona | 5000-12000 Optiona |
| Viewing angle(H/V) | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| Luminance/Color Uniformity | ≥97% | ≥97% | ≥97% | ≥97% | ≥97% |
| Constrast ratio | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 | 10000 : 1 |
| Frame Frequency | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Gray scale | 16bit | 16bit | 16bit | 16bit | 16bit |
| Refresh rate(Hz) | 3840 | 3840 | 3840 | 3840 | 3840 |
| Max consumption(W/㎡) | 1400 | 1000 | 900 | 850 | 850 |
| Avg. consumption(W/㎡) | 400-600 | 300-500 | 300-500 | 200-300 | 200-300 |
| Control mode | USB/LAN/WIFI/4G cloud(Optional) |
| Working Voltage | AC100-240V,50/60Hz |
| Working temp/Humidity(℃/RH) | ,-20~60℃/10%~85% |
| Stock temp/Humidity(℃/RH) | -20~60℃/10%~85% |
| Standard | KC/CCC/CE/RoHS/FCC |
Indoor LED Poster Screen
1. COB design adapts to P1.86, P2.0, P2.5.SMD design adapts to P1.25, P1.53, P1.86, P2.0, P2.5, P3.076 pixle.
2. High definition and high refresh rate
3. Super slim just 1.5inch thickness.
4. Popular base with wheels for easy move.
5. Support WIFI,4G,USB,Network cable.
6. Separate working or multiple screens seamless splicing working.
